Supermicro SSG-6049P-E1CR45H: 4U SuperStorage Server with 45-Bays

• Mainboard Supermicro X11DSC+, Intel® C621 chipset
• Dual Socket P (LGA 3647), 2nd Gen Intel Xeon Scalable Processors Up to 28 Cores, support 205W TDP
• 24x DIMM slots, up to 6TB RAM DDR4-2933MHz ECC
• 1x RJ45 dedicated IPMI LAN port
• 45x 3.5″ hot-swap SAS3/SATA3 drive bays, 2x 2.5″ hot-swap SATA drive bays (rear), optional: 6x NVMe bays
• SAS3 (12Gbps) via Broadcom 3108; HW RAID RAID 0, 1, 5, 6, 10, 50, 60
• Graphics ASPEED AST2500 BMC
• 2 USB 3.0 ports (rear), 1 VGA D-Sub connector port
